Velo Orange Orbital Rim
Velo Orange Orbital Rim
Velo Orange Orbital Rim
Velo Orange Orbital Rim

Velo Orange Orbital Rim

Velo Orange
$150.00 CAD $150.00 CAD
Diameter: 20"
Color: Polished Silver
Spoke count: 32h

You can't add more Velo Orange Orbital Rim in 20" / Polished Silver / 32h to cart

Disc-brake, tubeless-compatible all-rounder rims
Description

VO's new rim is here, following on from their classic box rims with a new disc-only v-profiled all-rounder.

The Orbital Rim is a modern, wide-profile, tubeless compatible powerhouse designed for the rigours of loaded touring, gravel riding, backcountry exploration, and everything in between.

With a generous internal width, the Orbital is specifically engineered to support high-volume tires from 45mm up to 2.5". This width provides a superior tire profile, allowing you to run lower pressures for maximum grip and comfort without the "squirm" associated with narrow rims. Whether you’re building up an adventure rig, a chunky-tire gravel machine, or rowdy commuter, the Orbital offers the perfect balance of lightweight agility and reliability.

  • Material: 6061-T6 Aluminum
  • Brake Compatibility: Disc Brake Only
  • Internal Width: 27mm
  • External Width: 31.8mm
  • 20":
    • ERD: 386.5mm
    • BSD: 406mm
    • Weight: 284g
  • 650B:
    • ERD: 565mm
    • BSD: 584mm
    • Weight: 414g
  • 700C/29er:
    • ERD: 603mm
    • BSD: 622mm
    • Weight: 447g
  • 32":
    • ERD: 665.5mm
    • BSD: 686mm
    • Weight: 489g

Please note, depending on your hub choice we may not have spokes to build a 32" wheel. At the moment in Canada, those are hard to find outside specialist unicycling operations. It's a new wheel size people are trying out, and things are up in the air about it.

Orders over a minimum threshold ship for free within Canada, with a flat rate for smaller orders. International orders are calculated, and US orders will have tariffs applied in the cart as a line item.
