Farets Chunk Frame and Fork

Vendor: CRUMBWORKS
Regular price $2,200.00 CAD Sale price $2,200.00 CAD
Size: Raw Clear L

You can't add more Farets Chunk Frame and Fork in Raw Clear L to cart

An ATB for good-looking riding

Description

We've paid close attention to the Crumbworks Chunk since we visited the shop back in March 2023 and caught a glimpse of Keita's prototype! It's an incredible frame that tastefully mixes old and new standards, has elegant swooping curved tubes, and rides just right. The original fillet brazed Chunk is made-to-order in Japan by Raizin works. The Farets Chunk is a more accessible, Taiwan-made version.

Check out Julian's Japan-made Chunk here.

Specs

Handmade in Taiwan, TIG welded.

  • Tubing: Heat-treated 4130 CrMo
  • Head Tube Diameter  1" Threaded
  • Bottom Bracket: 68mm English (BSA) Threaded
  • Fork Spacing: 12x100mm
  • Rear Spacing: 12x142mm
  • Seatpost Diameter: 27.2mm (Stealth dropper post routing)
  • Disc Brake Type: Flat mount for 160mm rotors
  • Maximum Tire Size: 27.5x2.8
  • Chainring Clearance: 42t single
  • 3 sets bottle cage mounts
  • Rear rack and mudguard mounts
  • Full-length cable housing guides for derailleurs and brakes
  • Triple cage mounts fork
  • Stealth Dynamo routing
  • Kickstand plate

Geometry

  S (47cm) M (50cm) L (54cm)
Top Tube (Effective) 590mm 620mm 660mm
Seat Tube (C-T) 470mm 500mm 540mm
Head Tube Angle 69° 69° 69°
Seat Tube Angle 71° 71° 71°
Head Tube Length 185mm 200mm 230mm
Chainstay Length 470mm 470mm 470mm
BB Drop 50mm 50mm 50mm
Fork Rake 50mm 50mm 50mm
Fork Axle To Crown 410mm 410mm 410mm
Weight 3.05 Kg 3.25Kg 3.45 Kg

Bassi frames ship for flat rates in Canada, the US, and Europe. Please contact us for a quote in other regions.
